Air Dryer – SAD Series Industrial Air Compressor
Features
Product Details
SAD series Parameters
| Model | Air processing capacity (Nm³/min) |
cooling method | Intake pressure (Mpa) |
Pressure dew point | Voltage (V) |
Cooling power (hp) | Fan power(w) | Weigh (kg) |
Air volume (Nm³/h) |
Dimension (mm) |
| SAD-1SF | 1.2 | Air-cooled | 0.6~1.0 | 2-10℃ | 220 | 0.33 | 1×90 | 70 | 890 | 600*420*600 |
| SAD-2SF | 2.5 | 0.75 | 1×55 | 110 | 965 | 650*430*700 | ||||
| SAD-3SF | 3.6 | 1 | 1×150 | 130 | 3110 | 850*450*700 | ||||
| SAD-4.5SF | 5 | 1.5 | 1×250 | 150 | 5180 | 1000*490*730 | ||||
| SAD-6SF | 6.8 | 2 | 1×250 | 160 | 6220 | 1050*550*770 | ||||
| SAD-8SF | 8.5 | 2.5 | 2×190 | 200 | 8470 | 1200*530*946 | ||||
| SAD-12SF | 12.8 | 380 | 3 | 2×190 | 250 | 8470 | 1370*530*946 | |||
| SAD-15SF | 16 | 3.5 | 2×190 | 320 | 8470 | 1500*780*1526 | ||||
| SAD-20SF | 22 | 4.2 | 2×190 | 420 | 8470 | 1540*790*1666 | ||||
| SAD-25SF | 26.8 | 5.3 | 2×250 | 550 | 10560 | 1610*860*1610 | ||||
| SAD-30SF | 32 | 6.7 | 2×250 | 650 | 10560 | 1610*920*1872 | ||||
| SAD-40SF | 43.5 | 8.3 | 3×250 | 750 | 15840 | 2160*960*1763 | ||||
| SAD-50SF | 53 | 10 | 3×250 | 830 | 15840 | 2240*960*1863 | ||||
| SAD-60SF | 67 | 13.3 | 3×460 | 1020 | 18000 | 2360*1060*1930 | ||||
| SAD-80SF | 90 | 20 | 4×550 | 1300 | 40000 | 2040*1490*1930 |
Applications
Mechanical
Metallurgy
Instrumentation
Electronic Power
Medicine
Packing
Automobile Manufacture
Petrochemicals
Food
Textile
Our refrigerated air dryers are specifically designed to remove moisture from compressed air, ensuring your system is protected from condensation and corrosion. By eliminating these moisture-related issues, you can significantly improve the performance and lifespan of your equipment, thereby increasing efficiency and reducing maintenance costs.
One of the main advantages of our refrigerated air dryers is their low-maintenance design. Our dryers require minimal maintenance, providing maximum uptime for your operation. This means less time is spent on repairs and maintenance, increasing productivity and reducing production costs. Imagine the impact it can have on your bottom line when your system runs smoothly with minimal downtime.
In addition to their reliability and economical advantages, our refrigerated air dryers are also very easy to use. They come with user-friendly controls for hassle-free operation. Whether you are a small business owner or a large industrial facility, our air dryers can be easily integrated into your existing system without any complications.
Furthermore, our refrigerated air dryers are meticulously manufactured using high-quality materials and advanced technology. Its rugged construction ensures durability and long-lasting performance, even in harsh operating environments. This means you can rely on our air dryers to effectively remove moisture from compressed air, regardless of usage conditions.
