Nitrogen and Oxygen Generator – KSZD Series
Features
Product Details
KSZD Series (purity 99.5%) Parameters
| Model | N2 voulme (Nm³/h) |
Air consumption (Nm³/min) |
Input and output exhaust connection(mm) |
|
| KSZD-5 | 5 | 0.26 | DN15 | DN15 |
| KSZD-10 | 10 | 0.51 | DN15 | DN15 |
| KSZD-20 | 20 | 1.03 | DN25 | DN25 |
| KSZD-30 | 30 | 1.54 | DN25 | DN25 |
| KSZD-40 | 40 | 2.05 | DN25 | DN25 |
| KSZD-60 | 60 | 3.08 | DN25 | DN25 |
| KSZD-80 | 80 | 4.11 | DN40 | DN32 |
| KSZD-100 | 100 | 5.13 | DN40 | DN32 |
| KSZD-120 | 120 | 6.16 | DN40 | DN32 |
| KSZD-160 | 160 | 8.21 | DN50 | DN40 |
| KSZD-200 | 200 | 10.27 | DN50 | DN40 |
| KSZD-230 | 230 | 11.81 | DN50 | DN40 |
| KSZD-260 | 260 | 13.35 | DN65 | DN50 |
| KSZD-300 | 300 | 15.4 | DN65 | DN50 |
| KSZD-330 | 330 | 16.94 | DN65 | DN50 |
| KSZD-360 | 360 | 18.48 | DN65 | DN50 |
| KSZD-400 | 400 | 20.53 | DN65 | DN50 |
| KSZD-430 | 430 | 22.07 | DN80 | DN65 |
| KSZD-460 | 460 | 23.61 | DN80 | DN65 |
| KSZD-500 | 150 | 25.67 | DN80 | DN65 |
| KSZD-530 | 530 | 27.21 | DN80 | DN65 |
| KSZD-560 | 560 | 28.75 | DN80 | DN65 |
| KSZD-600 | 600 | 30.8 | DN80 | DN65 |
| KSZD-700 | 700 | 35.93 | DN100 | DN65 |
| KSZD-800 | 800 | 41.07 | DN100 | DN65 |
| KSZD-1000 | 1000 | 51.33 | DN100 | DN65 |
| KSZD-1200 | 1200 | 61.6 | DN125 | DN80 |
| KSZD-1500 | 1500 | 77.00 | DN125 | DN80 |
| KSZD-2000 | 2000 | 102.67 | DN150 | DN100 |
| KSZD-2500 | 2500 | 128.33 | DN150 | DN100 |
| *The N2 pressure listed in this table is 0.1~0.65MPa (gauge pressure) dew point: ≤-40℃ (under normal pressure) |
||||
KSZD Series (purity 99.999%) Parameters
| Model | N2 voulme (Nm³/h) |
Air consumption (Nm³/min) |
Input and output exhaust connection(mm) |
|
| KSZD-5F | 5 | 0.62 | DN15 | DN15 |
| KSZD-10F | 10 | 1.25 | DN25 | DN25 |
| KSZD-20F | 20 | 2.49 | DN25 | DN25 |
| KSZD-30F | 30 | 3.74 | DN40 | DN32 |
| KSZD-40F | 40 | 4.99 | DN40 | DN32 |
| KSZD-60F | 60 | 7.48 | DN50 | DN40 |
| KSZD-80F | 80 | 9.97 | DN50 | DN40 |
| KSZD-100F | 100 | 12.47 | DN50 | DN40 |
| KSZD-120F | 120 | 14.96 | DN65 | DN50 |
| KSZD-160F | 160 | 19.95 | DN65 | DN50 |
| KSZD-200F | 200 | 24.93 | DN80 | DN65 |
| KSZD-230F | 230 | 28.67 | DN80 | DN65 |
| KSZD-260F | 260 | 32.41 | DN100 | DN65 |
| KSZD-300F | 300 | 37.40 | DN100 | DN65 |
| *The N2 pressure listed in this table is 0.1~0.65MPa (gauge pressure) dew point: ≤-40℃ (under normal pressure) |
||||
Applications
Metallurgical Metal Working
Colliery
Petrochemical Industry
Food And Medicine
Electronic Power
