Screw Air Compressor (fixed/variable frequency) – OGFD Series

Short Description:

OGFD series screw air compressor, which is stable and reliable, the system is designed to operate under low pressure, with small stress on parts and low heat load, making the compressor operation more reliable.
Core technology and energy saving highlight the use of the “zhengli(ganey) host, which has won invention patents from five countries, to avoid energy loss caused by “over-pressure and re-expansion”
Accurately matched, the air exhausted by this series air compressor is the low-pressure air required by the user.


Product Detail

Product Tags

Features

Overload start protection

Smaller footprint

Automatic dual control

Easy to operate, more environmental friendly

Product Details

OGFD SERIES Parameters

Product Number Model Exhaust volum

(m3/min)

Minimum working

pressure (MPa)

Maximum working

pressure (MPa)

NoisedB(A) Motor power

(kW)

Exhaust

connection

Weight

(kg)

Demension

(mm)

OGFD55-3 0GFD-16.1/3 16.1 0.25 0.3 80 55 DN80 2285 2680x 1380x 1900
OGFD75-3 OGFD-22.0/3 22.0 75 2375
OGFD90-3 OGFD-26.0/3 26.0 90 DN100 3490 3140x 1670x2180
OGFD110-3 OGFD-32.0/3 32.0 110 3795
OGFD132-3 OGFD-36.6/3 36.6 132 DN125 5100 3315 ×1690×2200
OGFD160-3 OGFD-43.0/3 43.0 160
OGFD55-4 OGFD-13.5/4 13.5 0.25 0.4 80 55 R2½” 1800 2200×1260×1860
OGFD75-4 OGFD-20.2/4 20.2 75 DN80 2375 2680×1380×1900
OGFD90-4 OGFD-24.0/4 24.0 90 2450
OGFD110-4 OGFD-28.0/4 28.0 110 DN100 3795 3140×1670×2180
OGFD132-4 OGFD-33.3/4 33.3 132 3850
OGFD160-4 OGFD-40.2/4 40.2 160 DN125 5200 3315×1690×2200
OGFD185-4 OGFD-45.0/4 45.0 185
OGFD55-5 OGFD-12.3/5 12.3 0.45 0.5 80 55 R2½” 1800 2200×1260×1860
OGFD75-5 OGFD-16.1/5 16.1 75 DN80 2375 2680×1380×1900
OGFD90-5 OGFD-20.2/5 20.2 90 2450
OGFD110-5 OGFD-23.8/5 23.8 110 DN100 3795 3140×1670×2180
OGFD132-5 OGFD-29.5/5 29.5 132 3850
OGFD160-5 OGFD-36.0/5 36.0 160 DN125 5200 3315×1690×2200
OGFD185-5 OGFD-39.0/5 39.0 185
OGFD200-5 OGFD-43.0/5 43.0 200





Applications

Mechanical

Mechanical

Metallurgy

Metallurgy

Electronic-Power

Electronic Power

medical

Medicine

packing

Packing

Chemical-Industry

Chemical Industry

food

Food

Textile

Textile
